Saturn V S-IC cutaway.jpg

Original file (1,024 × 786 pixels, file size: 165 KB, MIME type: image/jpeg)

This file is from Wikimedia Commons and may be used by other projects. The description on its file description page there is shown below.

Summary

DescriptionSaturn V S-IC cutaway.jpg	English: This is a cutaway view of the Saturn V first stage, known as the S-IC, detailing the five F-1 engines and fuel cells. The S-IC stage is 138 feet long and 33 feet in diameter, producing more than 7,500,000 pounds of thrust through the five F-1 engines that are powered by liquid oxygen and kerosene. Four of the engines are mounted on an outer ring and gimbal for control purposes. The fifth engine is rigidly mounted in the center. When ignited, the roar produced by the five engines equals the sound of 8,000,000 hi-fi sets.
Date	circa 1968 date QS:P,+1968-00-00T00:00:00Z/9,P1480,Q5727902
Source	https://images.nasa.gov/details-9903033 (image link)
Author	NASA/MSFC
